Destined for installation in water supply systems and central heating installations.
Maximum temperature: 100⁰C
Maximum pressure: 1,0 MPa
Material: brass
2-year warranty
| INDEX | A [inch] | B [mm] | C [mm] | D [mm] | Size | Collective packaging [pcs] | EAN code | Net weight (kg) |
| M.N.15 | G1/2 | 15 | 24 | 20 | 1/2″x15mm | 30/600 | 5900308732953 | 0,021 |
| M.N.18 | G1/2 | 18 | 24 | 30 | 1/2″x18mm | 25/500 | 5900308732960 | 0,030 |
| M.N.22 | G3/4 | 22 | 31 | 26 | 3/4″x22mm | 20/400 | 5900308732977 | 0,040 |
| M.N.28 | G1 | 28 | 39 | 36 | 1″x28mm | 15/150 | 5900308732984 | 0,081 |
